105 Thermally Broken Double Hung Window
The 105 Thermally Broken Double Hung Window is a thermally broken aluminium window with a 125 mm frame. A thermally broken double or single hung window with a traditional look for period homes. On the factory's test figures it rates about Uw 1.5 W/m²K and Rw+C 40–45 dB. Made to your sizes and delivered to site anywhere in Australia; send your plans for a landed quote in 2 business days.
Specifications
| Frame depth | 125 mm |
|---|---|
| Aluminium | 6063-T5 Thermal Break aluminium Profile |
| Wall thickness | 2.0 mm |
| Glazing | Automotive Grade toughened GlassDouble/Triple toughened GlassLaminated/Lowe/Reflective /Tinted Glass bottom, while the top sash stays fixed.When opening, the two sashes Double Glazing toughened 5 mm+12Ar+5 mm+Lace bar overlap, requiring no additional space to ventilate. |
| Hardware | Special Hardware For Double-Hung Window |
| Finish | Powder Coating, Anodizedwooden Grain.PVDF Coating |
| Opening | Single-Hung/Double-Hung |
| Standards | AS 2047 (windows and doors), glass to AS 1288; BAL-rated glazing on request |
| Supply | Made to measure, delivered to site Australia-wide, supply only |
Questions
Is the 105 Thermally Broken Double Hung Window thermally broken?
Yes. The frame has a polyamide thermal break between the inside and outside aluminium, which gives a factory Uw of about 1.5 W/m²K. That helps new homes meet the 7-star NCC energy rules and BASIX.
What glass can it take?
Per the factory catalogue: Automotive Grade toughened GlassDouble/Triple toughened GlassLaminated/Lowe/Reflective /Tinted Glass bottom, while the top sash stays fixed.When opening, the two sashes; Double Glazing toughened 5 mm+12Ar+5 mm+Lace bar overlap, requiring no additional space to ventilate.. Low-E, tinted, obscure and laminated glass are available, chosen to AS 1288 for the location.
What colours does it come in?
Powder coat in black, Monument, Surfmist white, Woodland Grey and other colours, plus metallic fluorocarbon (PVDF) and woodgrain finishes. All frames on one order come in the same colour batch.
How long does the 105 Thermally Broken Double Hung Window take to arrive?
Usually 6 to 10 weeks from signed shop drawings to delivery on site, depending on the order and the port. We confirm the date with your quote.
Ask about the 105 Thermally Broken Double Hung Window
Send sizes or plans and we price this series (and any others you need), delivered to site, within 2 business days.
